Key Information
- Rotation: Clockwise (looking from shaft end)
- 7/8” Diameter 13T SAE B splined shaft
- SAE B 2 hole mounting flange
- Front Pump displacement: 21 cc/rev (21L/Min per 1000 rpm)
- Middle Pump displacement: 12 cc/rev (12L/Min per 1000 rpm)
- Rear Pump displacement: 12 cc/rev (12L/Min per 1000 rpm)
Replaces the following JCB part numbers
Weight
Machine Fitment
- PUMPS HYDROSTATIC FITTINGS AND ADAPTORS 220414 TLT30G TCR 9822/0435
- PUMPS HYDROSTATIC FITTINGS AND ADAPTORS 1541747 220414 TLT25D TCR 9822/0435
- PUMPS HYDROSTATIC FITTINGS AND ADAPTORS 220414 TLT25G TCR 9822/0435
- PUMPS HYDROSTATIC FITTINGS AND ADAPTORS 220414 TLT30D TCR 9822/0435
