Key Information
- Rotation: Counter -Clockwise (looking from shaft end)
- 1” Diameter 15T SAE B-B splined shaft
- SAE B 4 hole mounting flange
- Front Pump displacement: 36 cc/rev (36L/Min per 1000 rpm)
- Middle Pump displacement: 19 cc/rev (19L/Min per 1000 rpm)
- Rear Pump displacement: 16 cc/rev (16L/Min per 1000 rpm)
Replaces the following JCB part numbers
Weight
Machine Fitment
- PUMP,(THREE STAGE) MAIN HYDRAULICS 80 L/MIN 541-70M MILITARY 9812/7250
- PUMP,(THREE STAGE) MAIN HYDRAULICS 80 L/MIN 541-70 SWAY TIER 2 9812/7060
- PUMP,(THREE STAGE) MAIN HYDRAULICS 80 L/MIN 536-70 9812/7075
- PUMP,(THREE STAGE) MAIN HYDRAULICS 80 L/MIN 541-70 TIER 2 9812/7060
- PUMP,(THREE STAGE) MAIN HYDRAULICS 80 L/MIN 541-70 Tier 3 9812/7300
- PUMP,(THREE STAGE) MAIN HYDRAULICS 80 L/MIN 531-70 SWAY TIER 2 9812/7060
- PUMP,(THREE STAGE) MAIN HYDRAULICS 80 L/MIN 535-95 SWAY Tier 2 9812/7000
- PUMP,(THREE STAGE) MAIN HYDRAULICS 80 L/MIN 535-95 Tier 3 9812/7085
- PUMP,(THREE STAGE) MAIN HYDRAULICS 80 L/MIN 531-70 TIER 2 9812/7060
- PUMP,(THREE STAGE) MAIN HYDRAULICS 80 L/MIN .536-70 9812/7075
- PUMP,(THREE STAGE) MAIN HYDRAULICS 80 L/MIN 531-70 Tier 3 9812/7300
- PUMP,(THREE STAGE) MAIN HYDRAULICS 80 L/MIN 535-95 Tier 2 9812/7000
- PUMP,(THREE STAGE) MAIN HYDRAULICS,AGS 125 L/MIN 535-95 Tier 3 9812/7085
- PUMP/MOTOR INSTALLATION ASSEMBLIES 3 STAGE, 80L/MIN 535-95 9822/0575
- PUMP/MOTOR INSTALLATION ASSEMBLIES 3 STAGE 531-70WM 9822/0090
- PUMP/MOTOR INSTALLATION ASSEMBLIES 3 STAGE 536-70AG+ 9822/0090
- PUMP/MOTOR INSTALLATION ASSEMBLIES 3 STAGE 541-70WM ALL 541-70 MODELS 9822/0090
- PUMPS GEAR 3 STAGE 536-70AG+ 9822/0090
- PUMPS GEAR 3 STAGE 531-70WM 9822/0090
- PUMPS GEAR 3 STAGE 536-60DS 9822/0090
- PUMPS GEAR 3 STAGE 541-70WM ALL 541-70 MODELS 9822/0090
